Attachment

PreviewCopy Anchor Link

Pick a file and watch the progress bar. Hit × mid-upload to cancel.

UsageCopy Anchor Link

import { z } from 'zod'
import { AutoForm } from '@vitnode/core/components/form/auto-form'
import { AutoFormFile } from '@vitnode/core/components/form/fields/file'
import { AutoFormFiles } from '@vitnode/core/components/form/fields/files'

const formSchema = z.object({
  avatar: z.number().nullable().default(null),
  gallery: z.array(z.number()).max(4).default([]),
})

<AutoForm
  formSchema={formSchema}
  fields={[
    {
      id: 'avatar',
      component: (props) => (
        <AutoFormFile
          {...props}
          allowedExtensions={['.png', '.jpg', '.webp']}
          label="Avatar"
          maxBytes={5 * 1024 * 1024}
          onUpload={uploadFile}
        />
      ),
    },
    {
      id: 'gallery',
      component: (props) => (
        <AutoFormFiles
          {...props}
          label="Gallery"
          maxBytes={5 * 1024 * 1024}
          maxItems={4}
          onUpload={uploadFile}
        />
      ),
    },
  ]}
/>

UploadingCopy Anchor Link

onUpload(file, { onProgress, signal }) uploads the picked File and returns the stored file ({ id, name, size, url, mimeType? }). The field saves its id.

• Call onProgress(fraction) with 0 to 1 to show a percentage. Skip it and the card shimmers instead.
• Pass signal to your request. Cancelling from the card aborts it, and any late response is ignored.
• Throw to fail. The file stays as an error card with a Try again button.

fetch can't report upload progress, so use XMLHttpRequest for the bar:

import type {
  AutoFormFileValue,
  FileUploadOptions,
} from '@vitnode/core/components/form/fields/file'

const uploadFile = async (
  file: File,
  { onProgress, signal }: FileUploadOptions,
): Promise<AutoFormFileValue> =>
  await new Promise((resolve, reject) => {
    const body = new FormData()
    body.append('file', file)

    const xhr = new XMLHttpRequest()
    xhr.open('POST', '/api/my-plugin/uploads')
    xhr.responseType = 'json'
    xhr.upload.onprogress = (event) => {
      if (event.lengthComputable) onProgress(event.loaded / event.total)
    }
    xhr.onload = () =>
      xhr.status < 300
        ? resolve(xhr.response)
        : reject(new Error('Upload failed'))
    xhr.onerror = () => reject(new Error('Upload failed'))
    signal.addEventListener('abort', () => xhr.abort())
    xhr.send(body)
  })

Removing and existing filesCopy Anchor Link

Removing a file from AutoFormFiles shows a toast with Undo, which puts it back in the same spot. Misclicks shouldn't cost a re-upload.

Editing a record with files? Pass file={existing} or files={existing} to show them.

LimitsCopy Anchor Link

Files are checked before upload, so nobody waits on a 2 GB video just to hear it's too big.

Files reorder by drag or keyboard. Check the same limits on your server: the browser check can't stop someone determined.

StatesCopy Anchor Link

Set state on Attachment: idle, uploading, processing, done (default) or error. In error, say what went wrong.

LayoutsCopy Anchor Link

• size: default, sm or xs for chat composers and tight lists.
• orientation="vertical" turns it into a card with a big preview.
• AttachmentGroup makes a horizontal scroll row that fades at the edges.
• AttachmentTrigger makes the whole attachment clickable. Render it as a link to open the file. Focus shows one ring on the attachment, not two.
• AttachmentTitle keeps the extension visible and truncates the rest: quarterly-rep….pdf.

AccessibilityCopy Anchor Link

• Give every AttachmentAction an aria-label naming the file: "Remove report.pdf". Plain "Remove" is a riddle when there are five files.
• Previews sit next to the file name, so alt="" is right.
• The fields announce reordering and list each rejected file with the reason.
• The whole drop zone is clickable. It only lights up when the drag carries files.
• On touch screens, actions and drag handles grow to a 40px hit area.
