Routes

Start by creating a plugin. A plugin's src/routes.ts is its promise to the app: which URLs it owns, and which module renders each one. The host turns that promise into lazy TanStack Start routes—no copied page files, no drama.

Simple route

You can declare a single page with a path and a lazy component:

import { definePluginRoutes, lazy, page } from '@vitnode/core/routing'

export const routes = definePluginRoutes([
  page('/notes', {
    component: lazy(() => import('./pages/note-page')),
    messages: ['@acme/site-notes.home'],
  }),
])

import { useTranslations } from 'use-intl'

const NotePage = () => {
  const t = useTranslations('@acme/site-notes.home')

  return (
    <div className="container mx-auto max-w-2xl p-4">
      <h1 className="text-2xl font-semibold tracking-tight text-balance">
        {t('title')}
      </h1>
    </div>
  )
}

export default NotePage

The messages array specifies which translation namespaces this page requires. A namespace must always be a dotted path into your plugin's message tree (such as @acme/site-notes.home rather than the bare plugin ID), allowing VitNode to only download the strings that this screen renders. For more details on message structure and limits, see the Namespaces and Translating Pages guides.

Render without the main layout

Every route picks a shell with area. The default is 'main', which frames the page in the host's public layout—header, breadcrumbs, navigation, footer.

Set area: 'blank' for a page that should stand on its own: an embed, a kiosk screen, a print view, a checkout step with nothing to wander off to.

import { definePluginRoutes, lazy, page } from '@vitnode/core/routing'

export const routes = definePluginRoutes([
  page('/notes/embed', {
    area: 'blank',
    component: lazy(() => import('./pages/notes-embed-page')),
  }),
])

A blank page is mounted at the root of the host's route tree, so it still gets the document, the theme, the providers, and translations. It simply has no chrome around it—which also means no breadcrumb trail, so give the page its own way back.

Only a top-level route chooses an area. Every route nested in a layout() renders in the shell its layout renders in, so it may not declare one of its own.

Dynamic route

Use :slug for dynamic segments. VitNode converts it to TanStack Start's internal $slug spelling while keeping your plugin portable.

import { definePluginRoutes, lazy, page } from '@vitnode/core/routing'

export const routes = definePluginRoutes([
  page('/notes/:slug', {
    component: lazy(() => import('./pages/note-page-slug')),
  }),
])

import type { PluginRoutePageProps } from '@vitnode/core/routing'

const NotePage = ({ params }: PluginRoutePageProps) => {
  return (
    <article className="container mx-auto max-w-3xl p-4">
      <h2 className="text-3xl font-semibold tracking-tight text-balance">
        {params.slug}
      </h2>
    </article>
  )
}

export default NotePage

Metadata (Head)

The head function returns the page's <title> and <meta> tags. It runs after the loader, so it can use the data to make a unique title, description, and other SEO tags.

import {
  definePluginRoute,
  type PluginRoutePageProps,
} from '@vitnode/core/routing'

export const route = definePluginRoute({
  head: ({ params }) => ({
    description: 'A note delivered by the Site notes plugin.',
    title: params.slug,
  }),
})

const NotePage = ({ params }: PluginRoutePageProps) => {
  return (
    <article className="container mx-auto max-w-3xl p-4">
      <h2 className="text-3xl font-semibold tracking-tight text-balance">
        {params.slug}
      </h2>
    </article>
  )
}

export default NotePage

Localizing metadata

head runs outside the React component tree—during SSR and on every navigation—so hooks like useTranslations cannot reach it. Instead, head receives t, a translator over the namespaces the route declared in messages:

page('/notes/:slug', {
  component: lazy(() => import('./pages/note-page-slug')),
  messages: ['@acme/site-notes.home'],
})

import { definePluginRoute } from '@vitnode/core/routing'

export const route = definePluginRoute({
  head: ({ params, t }) => ({
    description: t('@acme/site-notes.home.desc'),
    title: `${t('@acme/site-notes.home.note')}: ${params.slug}`,
  }),
})

Keys are full dotted paths, namespace included. A component scopes itself once with useTranslations('@acme/site-notes.home') and then asks for t('title'); in head there is no component to scope, so the whole key is spelled out.

Values interpolate the same way they do in a component:

head: ({ t }) => ({
  title: t('@acme/site-notes.home.greeting', { name: 'Ada' }),
})

load receives the same t, for a title that depends on data you are already fetching:

export const route = definePluginRoute({
  load: async ({ params, t }) => {
    const note = await findNote(params.slug)

    return { heading: `${t('@acme/site-notes.home.note')}: ${note.title}` }
  },
  head: ({ loaderData }) => ({ title: loaderData?.heading }),
})

Loaders

Fetch data in load. It runs on the server during SSR and on the client for subsequent navigations. Data returned from load is automatically passed to both head (for dynamic metadata) and the page component as loaderData.

import {
  definePluginRoute,
  type PluginRoutePageProps,
} from '@vitnode/core/routing'

interface Note {
  content: string
  title: string
}

export const route = definePluginRoute({
  load: async ({ params }): Promise<Note> => {
    return {
      content: 'Loaded securely from your plugin loader.',
      title: `Note: ${params.slug}`,
    }
  },
  head: ({ loaderData, params }) => ({
    description: loaderData?.content,
    title: loaderData?.title ?? params.slug,
  }),
})

const NotePage = ({ loaderData }: PluginRoutePageProps<Note>) => {
  return (
    <article className="container mx-auto flex max-w-3xl flex-col gap-4 p-4">
      <h1 className="text-3xl font-semibold tracking-tight text-balance">
        {loaderData.title}
      </h1>
      <p className="text-muted-foreground leading-relaxed text-pretty">
        {loaderData.content}
      </p>
    </article>
  )
}

export default NotePage

Breadcrumbs

Declare a crumb directly in definePluginRoute to contribute to the public header or AdminCP breadcrumb trail.

Because breadcrumb renders as a React component within the route's declared namespaces, useTranslations from use-intl works out of the box:

import { definePluginRoute } from '@vitnode/core/routing'
import { useTranslations } from 'use-intl'

export const route = definePluginRoute({
  breadcrumb: () => {
    const t = useTranslations('@acme/site-notes.home')

    return t('title')
  },
})

For dynamic routes, the crumb receives { loaderData } and can combine dynamic records with localized copy:

import { definePluginRoute } from '@vitnode/core/routing'
import { useTranslations } from 'use-intl'

export const route = definePluginRoute({
  load: async ({ params }): Promise<Note> => {
    return {
      content: 'Loaded securely from your plugin loader.',
      title: params.slug,
    }
  },
  head: ({ loaderData, params }) => ({
    title: loaderData?.title ?? params.slug,
  }),
  breadcrumb: ({ loaderData }) => {
    const t = useTranslations('@acme/site-notes.home')

    return `${t('note')}: ${loaderData.title}`
  },
})

For nested trails, deferred crumbs, and AdminCP trails, see the Breadcrumbs guide.

Loading states

While a route's loader runs, VitNode displays its pendingComponent:

import { definePluginRoutes, lazy, page } from '@vitnode/core/routing'
import { TablePendingSkeleton } from '@vitnode/core/tanstack/pending'

export const routes = definePluginRoutes([
  page('/notes', {
    component: lazy(() => import('./pages/notes-page')),
    pendingComponent: TablePendingSkeleton,
  }),
])

VitNode ships pre-built skeleton shapes from @vitnode/core/tanstack/pending: TablePendingSkeleton, FeedPendingSkeleton, FormPendingSkeleton, CardsPendingSkeleton, ProfilePendingSkeleton, AuthPendingSkeleton, and RoutePendingSpinner.

To customize skeleton props (such as rows or className), rename the file to routes.tsx and return a JSX element:

page('/notes', {
  component: lazy(() => import('./pages/notes-page')),
  pendingComponent: () => <FeedPendingSkeleton rows={4} />,
})

If pendingComponent is omitted, the route falls back to the application's global defaultPendingComponent. Learn more in the Loading States guide.

Missing pages

When a loader cannot find what the URL requested, throw notFound() from @tanstack/react-router to activate the route's notFound component:

import { notFound } from '@tanstack/react-router'
import { definePluginRoute } from '@vitnode/core/routing'

export const route = definePluginRoute({
  load: async ({ params }) => {
    const note = await findNote(params.slug)

    if (!note) {
      throw notFound()
    }

    return note
  },

  notFound: () => (
    <div className="container mx-auto p-4">
      <p className="text-muted-foreground leading-relaxed">No such note.</p>
    </div>
  ),
})

Unlike pendingComponent, notFound is part of the lazy page chunk and costs unvisited routes nothing. If omitted, the route falls through to the application's global defaultNotFoundComponent, preserving the application layout and navigation shell. Learn more in the Errors & Not Found guide.

Catch-all routes

A * segment matches every remaining segment of the URL, allowing a single route to own an entire subtree. It must be the final segment of a path and is only permitted on page() declarations (a layout ending in * would match before its child routes):

import { definePluginRoutes, lazy, page } from '@vitnode/core/routing'

export const routes = definePluginRoutes([
  page('/notes/*', {
    component: lazy(() => import('./pages/notes-catch-all')),
  }),
])

The page reads the matched trailing path from params._splat:

import type { PluginRoutePageProps } from '@vitnode/core/routing'

const NotesCatchAll = ({ params }: PluginRoutePageProps) => {
  const segments = (params._splat ?? '').split('/').filter(Boolean)

  return (
    <div className="container mx-auto max-w-3xl p-4">
      <p className="text-muted-foreground leading-relaxed">
        {segments.join(' / ')}
      </p>
    </div>
  )
}

export default NotesCatchAll

Route protection (requires)

Protect pages or entire layouts by declaring requires. VitNode checks the visitor's authentication state before the route chunk downloads:

import { definePluginRoutes, lazy, page } from '@vitnode/core/routing'

export const routes = definePluginRoutes([
  page('/notes/new', {
    component: lazy(() => import('./pages/new-note-page')),
    requires: 'authenticated',
  }),
])

Nested routes and layouts

A layout() wraps child routes in a shared UI frame without claiming a URL segment of its own. Use index() to render a page at the layout's root path.

Every path nested inside a layout is relative to its parent:

import {
  definePluginRoutes,
  index,
  layout,
  lazy,
  page,
} from '@vitnode/core/routing'

export const routes = definePluginRoutes([
  layout('/notes', {
    component: lazy(() => import('./pages/notes-layout')),
    messages: ['@acme/site-notes.home'],
    children: [
      index({
        component: lazy(() => import('./pages/notes-index-page')),
      }),
      page(':slug', {
        component: lazy(() => import('./pages/note-page-slug')),
      }),
    ],
  }),
])

A layout component renders {children}:

import { useTranslations } from 'use-intl'

const NotesLayout = ({ children }: { children: React.ReactNode }) => {
  const t = useTranslations('@acme/site-notes.home')

  return (
    <div className="container mx-auto flex max-w-4xl flex-col gap-6 p-4">
      <header className="border-b pb-4">
        <h1 className="text-2xl font-bold tracking-tight text-balance">
          {t('title')}
        </h1>
      </header>
      <main>{children}</main>
    </div>
  )
}

export default NotesLayout

AdminCP routes

Mount a screen in the staff-only Admin Control Panel by adding area: 'admin'. It automatically inherits the AdminCP shell, sidebar, and staff authentication guard:

page('/admin/notes', {
  area: 'admin',
  component: lazy(() => import('./pages/admin-notes-page')),
  messages: ['@acme/site-notes.admin'],
})

Search parameters

Type and validate query strings (like pagination or filters). Declare search on the route for eager URL-level validation before code chunks load:

page('/notes', {
  component: lazy(() => import('./pages/notes-page')),
  search: (input: Record<string, unknown>) => ({
    page: Number(input.page) || 1,
  }),
})

The component receives typed search values and a navigate helper:

import type { PluginRoutePageProps } from '@vitnode/core/routing'

interface NotesSearch {
  page: number
}

const NotesPage = ({
  navigate,
  search,
}: PluginRoutePageProps<undefined, NotesSearch>) => (
  <div className="container mx-auto p-4">
    <button
      className="inline-flex items-center rounded-md bg-primary px-4 py-2 text-sm font-medium text-primary-foreground hover:bg-primary/90"
      onClick={() => void navigate({ search: { page: search.page + 1 } })}
      type="button"
    >
      Next Page ({search.page})
    </button>
  </div>
)

export default NotesPage
